Demo 28: How to use Arduino ESP32 BLE (Bluetooth Low Energy) as a GATT client

1. Introduction
In this tutorial I will show you how to turn ESP32 BLE a GATT client so that it can connect to another BLE device that act as GATT server. When connecting to GATT server, GATT client can control or request data from GATT server. For example: GATT server is a device that can measure Heart Rate and GATT client request Heart Rate data and send it to a server so that the doctor can monitor patients remotely. In order to make this demo we will use 2 ESP32s and Demo 26. An ESP32 will act as a GATT server and an ESP32 will act as a GATT client.
The role of GATT client:
- Send command to GATT server to turn ON/OFF LED
- Registering BLE notification to monitor the temperature of GATT server.
The role of GATT server:
- Receive the Write command of GATT client and convert it to LED state
- Sending its temperature to GATT client using BLE notification
2. Software
Using GATT server code in Demo 26 to flash for one ESP32
Using GATT client code below. I wrote many comments in the code so that you can understand it easily.

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
#pragma GCC diagnostic push
#pragma GCC diagnostic warning "-fpermissive"
#include <stdint.h>
#include <string.h>
#include <stdbool.h>
#include <stdio.h>
#include "controller.h"
#include "bt.h"
#include "bt_trace.h"
#include "bt_types.h"
#include "btm_api.h"
#include "bta_api.h"
#include "bta_gatt_api.h"
#include "esp_gap_ble_api.h"
#include "esp_gattc_api.h"
#include "esp_gatt_defs.h"
#include "esp_bt_main.h"

#pragma GCC diagnostic pop

#define GATTS_SERVICE_UUID_TEST_LED   0xAABB

//Declare callback functions
static void esp_gap_cb(esp_gap_ble_cb_event_t event, esp_ble_gap_cb_param_t *param);
static void esp_gattc_cb(esp_gattc_cb_event_t event, esp_gatt_if_t gattc_if, esp_ble_gattc_cb_param_t *param);
static void gattc_profile_event_handler(esp_gattc_cb_event_t event, esp_gatt_if_t gattc_if, esp_ble_gattc_cb_param_t *param);

/* name of BLE device that you want to connect to */
static const char device_name[] = "ESP_GATTS_IOTSHARING";
static bool connect = false;

// from Arduino Serial Monitor type 'on' to turn on led, 'off' to off LED
String command = "";

// BLE scan params
static esp_ble_scan_params_t ble_scan_params = {
    .scan_type              = BLE_SCAN_TYPE_ACTIVE,
    .own_addr_type          = BLE_ADDR_TYPE_PUBLIC,
    .scan_filter_policy     = BLE_SCAN_FILTER_ALLOW_ALL,
    .scan_interval          = 0x50,
    .scan_window            = 0x30
};

// profile info
#define PROFILE_ON_APP_ID 0

//we have 2 characteristics
#define CHAR_NUM 2
// index of characteristics in array for led ctrl and temp notify
#define CHARACTERISTIC_LED_CTRL_ID    0
#define CHARACTERISTIC_TEMP_NOTI_ID   1

//this structure holds the information of GATT profile
struct gattc_profile_inst {
    esp_gattc_cb_t gattc_cb;
    uint16_t gattc_if;
    uint16_t app_id;
    uint16_t conn_id;
    uint16_t start_handle;
    uint16_t end_handle;
    uint16_t char_handle[CHAR_NUM];
    esp_bd_addr_t remote_bda;
};

// this variable holds the information of GATT profile
static struct gattc_profile_inst test_profile = {
    .gattc_cb = gattc_profile_event_handler,
    .gattc_if = ESP_GATT_IF_NONE,       /* Not get the gatt_if, so initial is ESP_GATT_IF_NONE */
};

/*
This function write value to specific characteristic,
or sending WRITE request to GATT Server
*/
void set_led(uint8_t val){
    uint8_t state = val;
    esp_ble_gattc_write_char(test_profile.gattc_if,
                            test_profile.conn_id,
                            test_profile.char_handle[CHARACTERISTIC_LED_CTRL_ID],
                            sizeof(state),
                            &state,
                            ESP_GATT_WRITE_TYPE_RSP,
                            ESP_GATT_AUTH_REQ_NONE);
}
/*
This callback will will be invoked when GATT BLE events come.
Refer GATT Client callback function events here:
https://github.com/espressif/esp-idf/blob/master/components/bt/bluedroid/api/include/esp_gattc_api.h
*/
static void gattc_profile_event_handler(esp_gattc_cb_event_t event, esp_gatt_if_t gattc_if, esp_ble_gattc_cb_param_t *param)
{
    uint16_t conn_id = 0;
    esp_ble_gattc_cb_param_t *p_data = (esp_ble_gattc_cb_param_t *)param;
    switch (event) {
        case ESP_GATTC_REG_EVT:{
            esp_ble_gap_set_scan_params(&ble_scan_params);
            Serial.printf("\nESP_GATTC_REG_EVT\n");
            break;
        }
        /* when connection is set up, the event comes */
        case ESP_GATTC_OPEN_EVT: {
            conn_id = p_data->open.conn_id;
            memcpy(test_profile.remote_bda, p_data->open.remote_bda, sizeof(esp_bd_addr_t));
            esp_ble_gattc_search_service(gattc_if, conn_id, NULL);
            test_profile.gattc_if = gattc_if;
            test_profile.conn_id = conn_id;
            Serial.printf("\nESP_GATTC_OPEN_EVT\n");
            break;
        }
        // When GATT service discovery result is got, the event comes
        case ESP_GATTC_SEARCH_RES_EVT: {
            esp_gatt_srvc_id_t *srvc_id = (esp_gatt_srvc_id_t *)&p_data->search_res.srvc_id;
            conn_id = p_data->search_res.conn_id;
   // The service may have many characteristics but we only care GATTS_SERVICE_UUID_TEST_LED
            if (srvc_id->id.uuid.len == ESP_UUID_LEN_16 && srvc_id->id.uuid.uuid.uuid16 == GATTS_SERVICE_UUID_TEST_LED) {
                Serial.printf("\nservice UUID16: %x\n", srvc_id->id.uuid.uuid.uuid16);
    // store start_handle and end_handle for later usage
                test_profile.start_handle = p_data->search_res.start_handle;
                test_profile.end_handle = p_data->search_res.end_handle;
            }
            Serial.printf("\nESP_GATTC_SEARCH_RES_EVT RES\n");
            break;
        }
  // When GATT service discovery is completed, the event comes
        case ESP_GATTC_SEARCH_CMPL_EVT: {
   // store connection id for later usage
            conn_id = p_data->search_cmpl.conn_id;
            esp_gattc_char_elem_t *char_elements;
            uint16_t char_offset = 0;
            uint16_t count = 0;
   // get characteristics of service. It just get characteristic from local cache, won't get from remote devices
            esp_gatt_status_t status = esp_ble_gattc_get_attr_count( test_profile.gattc_if,
                                           test_profile.conn_id,
                                           ESP_GATT_DB_CHARACTERISTIC,
                                           test_profile.start_handle,
                                           test_profile.end_handle,
                                           ESP_GATT_INVALID_HANDLE,
                                           &count);
            if (count > 0){
                char_elements = (esp_gattc_char_elem_t *)malloc(sizeof(esp_gattc_char_elem_t) * count);
                status = esp_ble_gattc_get_all_char(test_profile.gattc_if,
                                          test_profile.conn_id,
                                          test_profile.start_handle,
                                          test_profile.end_handle,
                                          char_elements, &count, char_offset);
                for(int i=0; i<count; i++){
                    Serial.printf("\n%d) char uuid = %x, char_handle = %d\n", i, char_elements[i].uuid.uuid.uuid16, char_elements[i].char_handle);
                }
    // store characteristic handles of CHARACTERISTIC_LED_CTRL_ID and CHARACTERISTIC_TEMP_NOTI_ID for later usage
                test_profile.char_handle[CHARACTERISTIC_LED_CTRL_ID] = char_elements[CHARACTERISTIC_LED_CTRL_ID].char_handle;
                test_profile.char_handle[CHARACTERISTIC_TEMP_NOTI_ID] = char_elements[CHARACTERISTIC_TEMP_NOTI_ID].char_handle;
                /*
    We use BLE notification to monitor temperature of GATT server.
    So we check if temp noti bit was set we will register to receive notification from GATT server
    */
                if (char_elements[CHARACTERISTIC_TEMP_NOTI_ID].properties & ESP_GATT_CHAR_PROP_BIT_NOTIFY){
                    Serial.printf("\nregister noti\n");
                    //if it set then we enable noti, the event ESP_GATTC_REG_FOR_NOTIFY_EVT will be raised when finishing
                    esp_ble_gattc_register_for_notify (gattc_if, test_profile.remote_bda, test_profile.char_handle[CHARACTERISTIC_TEMP_NOTI_ID]);
                }
                free(char_elements);
            }
            Serial.printf("\nESP_GATTC_SEARCH_CMPL_EVT\n");
            break;
        }
  // When register for notification of a service completes, the event comes
        case ESP_GATTC_REG_FOR_NOTIFY_EVT: {
            Serial.printf("\nESP_GATTC_REG_FOR_NOTIFY_EVT\n");
            break;
        }
        // when central device send data to this device, this event will be invoked and we print the temp data
        case ESP_GATTC_NOTIFY_EVT: {
            Serial.printf("\nESP_GATTC_NOTIFY_EVT\n");
            if(p_data->notify.value_len == 1){
                Serial.printf("\ntemperature from noti %d\n", p_data->notify.value[0]);
            }
            break;
        }
        default:
            break;
    }
}

/*
This callback will be invoked when GAP advertising events come.
Refer GAP BLE callback event type here:
https://github.com/espressif/esp-idf/blob/master/components/bt/bluedroid/api/include/esp_gap_ble_api.h
*/
static void esp_gap_cb(esp_gap_ble_cb_event_t event, esp_ble_gap_cb_param_t *param)
{
    uint8_t *adv_name = NULL;
    uint8_t adv_name_len = 0;
    switch (event) {
    case ESP_GAP_BLE_SCAN_PARAM_SET_COMPLETE_EVT: {
        Serial.printf("\nESP_GAP_BLE_SCAN_PARAM_SET_COMPLETE_EVT\n");
        //the unit of the duration is second
        uint32_t duration = 30;
        esp_ble_gap_start_scanning(duration);
        break;
    }
    case ESP_GAP_BLE_SCAN_START_COMPLETE_EVT:
        Serial.printf("\nESP_GAP_BLE_SCAN_START_COMPLETE_EVT\n");
        //scan start complete event to indicate scan start successfully or failed
        if (param->scan_start_cmpl.status != ESP_BT_STATUS_SUCCESS) {
            Serial.printf("\nScan start failed");
        }
        break;
    /* processing scan result */
    case ESP_GAP_BLE_SCAN_RESULT_EVT: {
        esp_ble_gap_cb_param_t *scan_result = (esp_ble_gap_cb_param_t *)param;
        switch (scan_result->scan_rst.search_evt) {
        case ESP_GAP_SEARCH_INQ_RES_EVT:
            Serial.printf("\nESP_GAP_BLE_SCAN_RESULT_EVT\n");
            adv_name = esp_ble_resolve_adv_data(scan_result->scan_rst.ble_adv, ESP_BLE_AD_TYPE_NAME_CMPL, &adv_name_len);
            if (adv_name != NULL) {
                if (strlen(device_name) == adv_name_len && strncmp((char *)adv_name, device_name, adv_name_len) == 0) {
                    /* if connection is established then stop scanning */
                    if (connect == false) {
                        connect = true;
                        Serial.printf("\nConnect to the remote device %s\n", device_name);
                        esp_ble_gap_stop_scanning();
                        esp_ble_gattc_open(test_profile.gattc_if, scan_result->scan_rst.bda, true);
                    }
                }
            }
            break;
        case ESP_GAP_SEARCH_INQ_CMPL_EVT:
            Serial.printf("\nESP_GAP_SEARCH_INQ_CMPL_EVT\n");
            break;
        default:
            break;
        }
        break;
    }
    case ESP_GAP_BLE_SCAN_STOP_COMPLETE_EVT:
        Serial.printf("\nESP_GAP_BLE_SCAN_STOP_COMPLETE_EVT\n");
        if (param->scan_stop_cmpl.status != ESP_BT_STATUS_SUCCESS){
            Serial.printf("\nScan stop failed\n");
        } else {
            Serial.printf("\nStop scan successfully\n");
        }
        break;
    case ESP_GAP_BLE_ADV_STOP_COMPLETE_EVT:
        Serial.printf("\nESP_GAP_BLE_ADV_STOP_COMPLETE_EVT\n");
        if (param->adv_stop_cmpl.status != ESP_BT_STATUS_SUCCESS){
            Serial.printf("\nAdv stop failed\n");
        } else {
            Serial.printf("\nStop adv successfully");
        }
        break;
    default:
        break;
    }
}

static void esp_gattc_cb(esp_gattc_cb_event_t event, esp_gatt_if_t gattc_if, esp_ble_gattc_cb_param_t *param)
{
    /* If event is register event, store the gattc_if for each profile */
    if (event == ESP_GATTC_REG_EVT) {
        if (param->reg.status == ESP_GATT_OK) {
            test_profile.gattc_if = gattc_if;
        } else {
            Serial.printf("\nReg app failed, app_id %04x, status %d\n",
                    param->reg.app_id,
                    param->reg.status);
            return;
        }
    }
    do {
        /* ESP_GATT_IF_NONE, not specify a certain gatt_if, need to call every profile cb function */
        if (gattc_if == ESP_GATT_IF_NONE || gattc_if == test_profile.gattc_if) {
            if (test_profile.gattc_cb) {
                gattc_profile_event_handler(event, gattc_if, param);
            }
        }
    } while (0);
}

void ble_client_appRegister(void)
{
    esp_err_t status;

    Serial.printf("\nregister callback");
    //register the scan callback function to the gap module
    if ((status = esp_ble_gap_register_callback(esp_gap_cb)) != ESP_OK) {
        Serial.printf("\ngap register error, error code = %x\n", status);
        return;
    }
    //register the callback function to the gattc module
    if ((status = esp_ble_gattc_register_callback(esp_gattc_cb)) != ESP_OK) {
        Serial.printf("\ngattc register error, error code = %x\n", status);
        return;
    }
    esp_ble_gattc_app_register(PROFILE_ON_APP_ID);
}

void gattc_client_test(void)
{
    esp_bluedroid_init();
    esp_bluedroid_enable();
    ble_client_appRegister();
}

void setup(){
  Serial.begin(115200);
  btStart();
  gattc_client_test();
}
/* processing Terminal command, type 'on' to turn on led, 'off' to off LED */
void loop(){
  if(Serial.available() > 0){
      while(Serial.available()){
          command += (char)Serial.read();
          if(command == "on"){
              Serial.println("ON");
              set_led(1);
          }else if(command == "off"){
              Serial.println("OFF");
              set_led(0);
          }
      }
      command = "";
  }
}
3. Result
Put 2 ESP32s near each other; restart ESP32 GATT server then restart ESP32 GATT client. After ESP32 GATT client connected to GATT server, from Terminal GATT client type "on" or "off" to turn ON/OFF LED and you can see the temperature data will be printed on the Terminal.

Post a Comment

14 Comments

Ladi said…
The demo code throws a lot of errors during compiling like:

ESP32_GATT_Client:148: error: 'esp_ble_gattc_get_characteristic' was not declared in this scope

esp_ble_gattc_get_characteristic(gattc_if, conn_id, &test_service, NULL);

^

ESP32_GATT_Client:151: error: 'ESP_GATTC_GET_CHAR_EVT' was not declared in this scope

case ESP_GATTC_GET_CHAR_EVT:

^

ESP32_GATT_Client:152: error: 'union esp_ble_gattc_cb_param_t' has no member named 'get_char'

if (p_data->get_char.status != ESP_GATT_OK) {

^

ESP32_GATT_Client:155: error: 'union esp_ble_gattc_cb_param_t' has no member named 'get_char'

printf("ESP_GATTC_GET_CHAR_EVT: conn_id = %x, status %d\n", p_data->get_char.conn_id, p_data->get_char.status);



Has anyone an idea what is wrong? The demo 27 compiles without errors.
Hi, please update your Arduino core for the ESP32. I think you are using the old version.
Ladi said…
Although installed only recently I update core. Since it didn't change anything, I installed core from scratch, so I'm sure I used the very latest core. Still the same result.

P.S.: Also function "esp_log_buffer_hex(...)" is defined somewhere else with different number of parameters. Had to change the function and the call to _esp_log_buffer_hex(...) to avoid that error.

Try to search the missed function, definition, ... in your core to ensure they ware available.

esp_log_buffer_hex you can rename it with myesp_log_buffer_hex
Jt86 said…
I have the same problems as Ladi. I deleted the core and reinstalled it from here https://github.com/espressif/arduino-esp32 and the arduino ide still compiles the same errors. How can I correct this?

ESP32_GATT_Client:148: error: 'esp_ble_gattc_get_characteristic' was not declared in this scope

esp_ble_gattc_get_characteristic(gattc_if, conn_id, &test_service, NULL);

^

ESP32_GATT_Client:151: error: 'ESP_GATTC_GET_CHAR_EVT' was not declared in this scope

case ESP_GATTC_GET_CHAR_EVT:

^

ESP32_GATT_Client:152: error: 'union esp_ble_gattc_cb_param_t' has no member named 'get_char'

if (p_data->get_char.status != ESP_GATT_OK) {

^

ESP32_GATT_Client:155: error: 'union esp_ble_gattc_cb_param_t' has no member named 'get_char'

printf("ESP_GATTC_GET_CHAR_EVT: conn_id = %x, status %d\n", p_data->get_char.conn_id, p_data->get_char.status);
Anonymous said…
At first thank you very much for your wonderful tutorials !
But I have the same problems like the other people who want to compile the gatt client sample code ..
My installation is brand new !
I wish you a nice day and maybe you have time to give us the right solution.
Thanks in advance !
cheers
Siegmar
Thank you all,

It seem the Arduino SDK has been updated. I will check it soon and update the demo. :)
updated new code which adapted new sdk version
Unknown said…
I have run this on an ESP32 and it works. I modified it to work with a small hand-held BLE mouse device that uses the HID Device service with several characteristic reports. Connects and receives the reports via notifications.

However, I am having a problem with dis-connecting. If I turn off my BLE device the system hangs. I added the ESP_GATTC_CLOSE_EVT to the event handler, so I get a notification that the system recognized that the server disconnected, but cannot initiate another scan to try to re-connect. Any help would be appreciated.

Thank you
hi friend

Is your esp32 as a BLE client?

Regards
and you can try this in ESP_GATTC_CLOSE_EVT event using ESP.restart() first and if it not work then using ESP.reset() :)
Unknown said…
Yes, I am using the ESP32 as a BLE client. I will try the restart and reset. Will these reset the entire chip or just the bluetooth stack ?

I am using three reports under one service. Currently, I have to use one notification callback for all of the reports. Is there a way to assign a different notification callback to each report ?

Thanks
Hi friend

You can use one callback but in callback for every event you can check unique feature of them like id and if id is matched for a specific event then call specific function for that event.

Regards.
juanfe said…
You shoul add scan_result->scan_rst.ble_addr_type as parameter number 3 in line 222
esp_ble_gattc_open(test_profile.gattc_if, scan_result->scan_rst.bda, scan_result->scan_rst.ble_addr_type,true);
